What is 14/40 SOOW Portable Power Cable ?
14/40 SOOW Portable Power Cable is part of our Power Cables & Portable Cord line of Wire & Cable. 14/40 SOOW Portable Cable is composed of 40 bare copper conductors with a 41/30 stranding, an ethylene propylene diene monomer rubber (EPDM) insulation, and a chlorinated polyethylene (CPE) jacket. These cables are rated for a voltage of 600 volts, an amperage of 6 amps, have a temperature range of -40°C to 90°C, and weighs approximately 1787 lbs/MFT.
Inside 14/40 SOOW Portable Cable is normally another type of insulating material. It's EPDM (ethylene propylene diene monomer) or EP (ethylene propylene) rubber. These types of materials are part of the thermoset group of insulations. Through the thermoset process, the materials are literally squeezed onto the wires and then with heat and pressure become one with them. That means the insulation will never fade even if it's placed under extreme heat or other situations.
14/40 SOOW Portable Cord Specifications:
|
AWG Size |
14 |
|
No. of Cond. |
40 |
|
Conductor Stranding |
41/30 |
|
No. of Strands |
41 |
|
Strand Size |
30 |
|
Nom. Insul. Thick. (in) |
0.045 |
|
Jacket Thick |
0.125 |
|
Nom. O.D. of Cable (in) |
1.450 |
|
Amps |
6.0 |
|
Approx LBS/MFT |
1787 |
|
UL Style |
SOOW |
|
CSA Type |
SOOW |
|
Voltage |
600 |
|
Max. Temp |
90°C |
|
Cond. Material |
Bare Copper |
|
Insul. Material |
Ethylene Propylene Diene Monomer Rubber (EPDM) |
|
Jacket Material |
Chlorinated Polyethylene (CPE) |
|
Jacket Color |
Black |
14/40 SOOW Portable Cable Features:
600V Voltage Rating
Bare Annealed Copper Conductors
EPDM Insulation
Thermoset CPE Jacket
Rated -40 to 90°C
Resistant to Weather, Water, Oil, Solvents, Ozone, Aging and Abrasion
Flame Retardant
MSHA Listed
OSHA Acceptable
UL Listed
CSA Listed
Wires Have Paper Tape Separators
14/40 SOOW Portable Cord Applications
With 14/40 SOOW Portable Cord high flexibility and resistance to the effects of abrasion, chemicals, weather, and extended periods of sunlight, it is recommended for use as portable electrical power and portable control wire cable carrying voltage of up to 600 volts. The durable structure lends SOOW wiring to heavy-duty cable service applications including the following:
Industrial tools
Portable lights
Battery charters
Equipment that is typically exposed to oils, solvents, flame, and grease
Ground tests and motor leads
14/40 SOOW Portable Cord Standards:
UL Flexible Cord - UL Subject 62
CSA Flexible Cord - C22.2-49
MSHA Approved
RoHS Compliant
